Used Bagger Only Vertical Form and Fill

Stock# 70120003

Used- AMI Top Zip Recloseable Packaging System, Model D-2500-25-RH. Affixes a zipper along the top short side of polyethylene packages, 60 bags per minute. Zipper application is currently set up for 1629 type zipper. 220 Vac, 3 phase, 30 amp, 80 psi. Mfg 2000.

Stock# 72586001

Used-Bosch SVE3800 Vertical Form Fill and Seal Machine. Capable of speeds up to 120 bags per minute. Has a bag size range: width 60 mm 380 mm (2 1/3 15") x length 75 mm 600 mm (3 24"). Film specifications: Width 800 mm max (32" max) x Diameter: 650 mm max (26" max), Has print registration, market smart date coder, Allen Bradley RS Logix 5000 plc. Mfg. 2020.

Stock# 71772002

Used- Hayssen Ultimax CM-15 HPR Continuous Motion Washdown Vertical Form Fill Seal Bagger. Capable of speeds up to 130 Bags per Minute (depending on size and application). Suitable for structured, barrier type resistance sealed film, with bagsize range approximately 2" - 15" (width) 2" - 30" (length). Has top and bottom gusseting. Uses Allen Bradley Logix 5561 PLC controls, Allen Bradley Versa View 1200 HMI, Rexroth Servo drives and print registration. Last used in washdown facility and was running frozen sausage and meat products. AEK can mount and integrate fillers per application at an additional cost (combination scales, auger fillers, volumetric cup fillers, liquid/piston fillers etc). 30 amps. 1/60/460V. Currently equipped with a 15" former, inquire with sales representative about other available formers.

Stock# 72114001

Used- Hayssen Form and Fill Vertical Packager with Poly Film Jaws, Continuous Model 12-16HP. Year 2004. Has 3.5" former. Electrics 1/60/208/230V.

Stock# 70250002

Used-Matrix Vertical Form, Fill & Seal Machine, Model 916. Capable of speeds up to 70 cycles per minute. Has a package size range of: 2" to 8" wide and 3" to 15" long. Has a 1/2" wide horizontally serrated seal jaw and printed film registration. Includes Norwood AKS-7 embosse date coder. Mistubishi PLC and LCD HMI. Stainless steel construction. Air requirements: 90 psi @ 20 CFM. 1/50-60/220V. Approximately 5,000 lbs. Last running snack foods.

Stock# 72628001

Used- Matrix Model 1416-R Vertical Form, Fill and Seal Machine. Capable of speeds up to 70 BPM (depending on application. Bag size range: 1.75" - 14" (width) x 2.5" - 15" or 60mm - 390mm (length). Currently setup with 10" wide x 1-1/2" thick seal jaw. Stainless Steel construction. Has printed film registration. Hole Punch and horizontal serrated knife. Parker touch screen operator HMI. Mitsubishi Melsec FX3u-32m PLC, Omron Sysdrive VFD. 3/60/240V, 20 amps.

Stock# 72752001

Used- Pac Worldwide Bubble Wrap Machine. The PACjacket3AB system automatically seals your product in a lightweight, ultra-protective bubble mailer made from a durable, moisture resistant, multi-layer blend of co-extruded polyethylene film. Quality, precision, and speed were what we had in mind for our customers when we developed the PACjacket automated system. Our new single web design produces a high quality seal that offers greater security for its contents by reducing the number of heat seals necessary to produce a finished package. This is the ultimate automated system for high volume e-commerce applications. On average the PACjacket machine produces 1520* bags per minute. Max roll size: 42" diameter by 38"wide. Uses standard 7/64" bubble film. Last used in cosmetics. Mfg. 2020

Stock# 72727042

Used-Premier Tech Model TFS-411 Vertical Form, Fill and Seal Machine, Model VFFS. Application: bulk materials; granular, pellet, power, flake, coarse aggregate, fibrous Production output rate: up to 22 bags per minute, product dependent Bag types: gusseted, pillow type, gusseted flat bottom Bag Dimensions: Face Width: Minimum: 13 inches Maximum: 17 inches Length: Minimum: 13 inches Maximum: 39 inches Side Gusset (if Used) Minimum: 3 .5 inches Maximum: 7 inches Bag specification: Bag material: Polyethylene, tubular film Film thickness: 4 - 8 mils Maximum roll diameter: 47 inches Maximum roll weight: 880 pounds Last used to fill wine corks into bulk bags.

Stock# 71093030

Used- Triangle Vertical Form Fill & Seal Machine, Model B22C/A918H1RN. 1/60/460V. Serial # 119985.

Stock# 72693001

Used- UVA Packaging Model Butler-4 Form and Fill Vertical Form Fill Seal Machine. Capable of speeds up to 120 BPM. Intermittent motion. Has a bag size range: 50mm - 220mm (width) x up to 400mm (length). Has belt pull down, print registration and set up for supported films.

Stock# 70431015

Used- Viking Masek M400 Vertical Form Fill and Seal. Capable up to 100 bags per minute. Intermittent motion. Bag size range: 3.93" - 15.75"W x 2.36" - 19.69"L. Siemens CPU, Pro-face touch screen HMI. 2 1/4" dia former. Vacuum film pull-down over bag former. 20.5" long longitudinal seal bar. Stainless steel construction. Last ran spices and was fed by an auger filler. Elec: 3/60/480V.

Stock# 72483001

Used- Wolf VPP-180 Mini-Master Vertical Form, Fill & Sealer Machine (Bagger Only). Capable of up to 100 bags per minute (depending on product and wrapping material). Bag size range: 50 to 180 mm (1.97" - 7.086") width x 120 to 320 mm (4.72" - 12.6") length. Film width 420mm (16.54"). Horizontal serration knife seal bar, top seal 1/2", bottom 1/2". Horizontal seal bar approximate 8-1/4" long x 1-3/4" wide. Vertical seal bar approximate 13" long x 1/4" wide. Allen Bradley compact logix L35E PLC, A/B panel plus 700 HMI, Sew Eurodrive Servo drive (for seal jaws). Has registration. Includes takeaway conveyor. 3/60/230 Volt.
