Used Non Plastic Extruders

Stock# 49122001

Used- Italpast Mac 60 Pasta Extruder. Output 42-48 kg/hr. Bin Capacity: 13 kg; 2.8 Kw, 60Hz, 220V & 3 phase. 80 x 95 x 160 cm. Approximate 195kg. Bronze dies with Teflon inserts. Rotini, small and jumbo shells, tube, fettucine, rigatoni and spaghetti dies. Includes 2 knives, one brand new.

Stock# 81116

Used- Bonnot Extruding System Consisting Of: (2) Bonnot 2" lab extruders, 20" long carbon steel jacketed barrels. Each driven by a 3 hp, 3/60/230/460 volt, 1770 rpm gearmotor, ratio 22.4:1. (2) 4" diameter tapered screw vertical feeders with jacketed feed hoppers, each driven by a 1-1/2 hp Reeves varispeed drive, minimum/maximum rpm 3.2/29.2. (2) Reliance SP500 VS drives. (1) 8" Wide dual sheet die. All mounted on a common frame.

Stock# 81117

USED: Bonnot extruding system consisting of (2) Bonnot 2" lab extruders, 20" long carbon steel jacketed barrels. Each driven by a 3 hp, 3/60/230/460 volt, 1770 rpm gearmotor, ratio 22.4:1. (2) 4" diameter tapered screw vertical feeders with jacketed feed hoppers, (1) driven by a 1-1/2 hp Reeves varispeed drive, min/max rpm 3.2/29.2; (1) driven by an SEW Eurodrive gearmotor. (2) Reliance SP500 VS drives. (1) 8" wide dual sheet die. All mounted on a common frame.

Stock# 46536004

Used- Bonnot Type Extruder, 304 Stainless Steel. Approximate 2-1/4" (57mm) diameter x 51-1/4" long cored screw, approximate 22.8 to 1 L/D ratio. 6" x 4-1/4" Feed with 2" diameter x 6" long packing screw. (4) 10-1/2" long jacketed barrel sections. Approximate 42-3/8" centerline height. Driven by 20 hp, 500 volt, 1750 rpm DC motor. Mounted on a carbon steel frame. Unit does not have a manufactures tag.

Stock# 41694003

Used- Teledyne Readco Continuous Crosshead Extruder, model 5, 304 stainless steel. 5 diameter screw segments, approximately 32 long overall length. Sections consist of: (1) 8 front secondary feed section with sight glass; (1) 12 middle main feed section with hopper, carbon steel jacket; (1) 12 end carbon steel jacket barrel section. Jacket rated 150 psi at 650 deg F. Driven by a 7-1/2 hp Sew variable speed motor, ratio 50.55 to 1, minimum/maximum rpm 12/71. Mounted on a stainless steel frame. Last used with a Teledyne Readco 5 continuous twin screw processor.

Stock# 43260001

Used- AMK Ram Fed Extruder. 321 Stainless steel feed chamber dimensions 21" front to back x 23" left to right. Equipped with an approximate 7" diameter x 36'' long aluminum discharge screw. Driven by a 3 hp, 3/60/208 volt, 1800/600 rpm US variable speed motor. Pneumatically operated ram feed.

Stock# 42024012

Used- Bonnot 8'' Extruder, Model 8-10-1/2, 316 Stainless Steel. 8" Diameter tapered to 10.5" diameter screw, 8" x 12" feed, jacketed grooved barrel. Driven by a 30 hp, 3/60/230/460 volt motor thru a reducer, ratio 31.4 to 1. No die plate. Mounted on a carbon steel frame. Serial# B3300, built 1994.

Stock# 42024013

Used- Bonnot 8" Extruder, Model 8"-SS, 316 Stainless Steel. 8" Diameter tapered to 10.5" diameter screw, 8" x 12" feed, jacketed grooved barrel. Driven by a 30 hp, 3/60/230/460 volt motor thru a reducer, ratio 31.4 to 1. No die plate. Mounted on a carbon steel frame. Serial# B3239. Built 1993.

Stock# 45702002

Used- The Bonnot Co. Model 10 EXT Single Screw Extruder, Carbon Steel. 10" Diameter x 72" long screw, 7 to 1 L/D ratio. (2) Grooved barrel sections (1) jacketed. Driven by a 100 hp, 3/60/230/460 volt, 1785 rpm motor thru a Dodge reducer, ratio 46.96 to 1. Mounted on a frame. Serial # B3373. Year 1999.

Stock# 45702004

Used- The Bonnot Co. Model 10 EXT Single Screw Extruder, Carbon Steel. 10" Diameter x 72" long screw, 7 to 1 L/D ratio. (2) Grooved barrel sections (1) jacketed. Driven by a 100hp, 3/60/460 volt, 1785 rpm motor thru a Dodge reducer, ratio 46.96 to 1. Mounted on a frame.

Stock# 45702006

Used- The Bonnot Co. Model 10 EXT Single Screw Extruder, Carbon Steel. 10" Diameter x 72" long screw, 7 to 1 L/D ratio. 20" x 16" feed throat, (2) 3" diameter x 18" long rotating packers, missing grooved barrel sections. Driven by a 100hp, 3/60/230/460 volt, 1780 rpm motor thru a reducer, ratio 46.79 to 1. Mounted on a frame. Serial# B3766.

Stock# 45702007

Used- The Bonnot Co. Model 10 EXT Single Screw Extruder, Carbon Steel. 10" Diameter x 72" long screw, 7 to 1 L/D ratio. (2) Grooved barrel sections (1) jacketed. Driven by a 100hp, 3/60/460 volt, 1765 rpm motor thru a Dodge reducer, ratio 46.96 to 1. Mounted on a frame. Serial# B3529, Year 1998.

Stock# 45702008

Used- Bonnot Co. Model 10 EXT Single Screw Extruder, Carbon Steel. 10" diameter x 72" long screw, 7 to 1 L/D ratio. (1) Grooved barrel section, (1) section missing. Driven by a 100hp, 3/60/230/460 volt, 1785 rpm motor thru a Dodge reducer, ratio 46.96 to 1. Mounted on a frame. Serial# B3305, Year 1994.

Stock# 45702010

Used- The Bonnot Co. Model 10 EXT Single Screw Extruder, Carbon Steel. 10" Diameter x 72" long screw, 7 to 1 L/D ratio. (2) grooved barrel sections (1) jacketed. Driven by a 75 hp, 3/60/230/460 volt, 1180 rpm motor thru a Dodge reducer, ratio 46.96 to 1. Mounted on a frame.
