Used Drum Dryers

Stock# 11252099

Used- Buflovak Double Drum Dryer for Vacuum Service. Rolls measure 32" diameter x 72" face and are hard chrome plated, Type Vacuum. Previously operated between .6 to .7 GPM feed rate, with vacuum level between 19-20 inches Hg, on extracts at a percentage of solids of 5% - 10%. Includes stainless steel vacuum encasing, Johnson rotary joints, stainless steel splash hood, spring type drum adjustment, pneumatically controlled knife assembly, Pendulum feed, (4) hinged doors on each side, lube system, stainless steel piping, control cabinet, etc. Complete with Nash 15 hp, Model XL45/7 vacuum pump. Includes Vilter stainless steel vertical condenser, rated for 250 psi at 300 degree F / -20 degree F (shell side) and 75 psi at 300 degree F / -20 degree F (tube side), surge drum and connected piping. Previously used in pharmaceutical environment.

Stock# 44813004

Used- R Simon Stainless Steel Chill Drum Dryer, Model 4718. 4m Long x 2m wide, 5.5 bar G, design pressure 6.1, bar design temperature -1 degree, hydraulic test pressure 9.1, 316 grade stainless steel. Includes CIP spray cleaning system, discharge belt conveyor 600 mm wide x 8500 mm long, freon Teflon scraper, 30 kw at 22 rpm, 415 volt. Manufactured 1997.

Stock# 50004001

Used GMF-Goudsche Mashinefabriek B.V. single drum dryer, 1508 mm (59.37") diameter x 3000 mm (117") st. side roll. Carbon steel chrome construction on product contact parts. 4350 liters (468 sq. ft). Max drum pressure rated 12 bar (180 psi) at 191 deg. C (375.8 deg F). Drum speed 4-16 rpm via a gearbox by a 12-45 HP/8-30 Kw-220/380volt/50cycle/3Ph-600-2200 rpm. Motor. (4) Left-Right order-rolls 221 mm (8.6") dia. x 3000 mm (117") st. side. (2) 5 section bronze discharge knives 150 mm (5.9") dia. x 2956 mm (115.3") long. Incl. (1) Stainless steel discharge screw conveyer 400 mm (15.6") dia. x 188" (4822 mm) st. side driven by a 1.65 HP/1.1 Kw-220/380volt/50cycle/3Ph motor. (1) Stainless steel inspection platform. Complete with stainless steel hood, air handling system and additional infrastructure. New 1978.

Stock# 50132001

Used- GL & V Double Drum Dryer. Chrome claded. Approximate 42" (1066.8 mm) diameter x 144" (3657.6 mm) straight side drums. Maximum temperature rated 150 PSI at 32 to 450 Degrees F (232C) temperature 16.8 hp/11.2 kW drive. Two (2) identical 8.4hp/5,6 kW motors. Dryer is equipped with stainless steel hood. Double screw discharge conveyers. On 4 legs. Operating panel.

Stock# 49938001

Used- Buflovak Double Drum Dryer. 12" diameter x 18" roll face width. Stainless steel drums and frame. Drums rated 160 psi at 350 degree F each. Cored rolls with rotary unions. Adjustable knife discharge. Adjustable drum gap. Driven by 1 hp, 230/460 volt variable speed motor drive. On base with motor drive.

Stock# 50311002

Used- American Double Drum Dryer, 32" x 120" Cast Iron. Model 42A. Cored rolls. Driven by a 15 hp, 3/60/230/460 volt, 1760 rpm gear motor, 5.1 ratio. Serial# 594.

Stock# 11453386

Used- Buflovak Double Drum Dryer. 32" diameter x 52" roll face width drums, carbon steel chrome plated drums, carbon steel frame. Drums rated 160 psi at 650 f each. Cored with rotary unions, adjustable knife discharge, adjustable drum gap. Driven by 10 hp, 230/460 volt variable speed XP motor drive, on base with motor drive. Mfg. 1989.

Stock# 50311001

Used- Buflovak Double Drum Dryer, 42" x 120" Cast Iron. Cored rolls. Driven by a 15 hp, 3/60/230/460 volt, 1750 rpm motor.

Stock# 14191061

Used- 48" Diameter Goslin Birmingham Chrome Plated Drum Flaker. Approximately 4' diameter x 4' face complete with 3 hp Reeves variable speed drive. Size 333-VIE=-18, output rpm 45 maximum/11.5 minimum, XP motor - 3/60/220/440V at 1735 rpm. Mfg.1966.

Stock# 48917001

Used- GMF Gouda T 15/40 KD Double Drum Dryer, 1508 MM (59.37") Diameter X 4000 MM (157.48") Face. Cast Iron Rolls. Not Chrome Plated.204 square feet per drum / 408 square foot total area. Drums rated 8.5 bar (123 psi) at 191 degrees C. MAWP 12 bar. Drum speed 1.5-15 rpm. 18.5 KW drive. Two (2) discharge augers. 560 mm diameter x 5,995 mm Long. Driven by 1.5 kW motor, 80 rpm. Dryer is equipped with stainless steel hood. Hydraulic bearing lube system. Mfg. 2012.

Stock# 48917002

Used- GMF Gouda T 15/40 KD Double Drum Dryer, 1508 MM (59.37") Diameter X 4000 MM (157.48") Face. Cast Iron Rolls. Not Chrome Plated. 204 square feet per drum / 408 square foot total area. Drums rated 8.5 bar (123 psi) at 191 degrees C. MAWP 12 bar. Drum speed 1.5-15 rpm. 18.5 KW drive. Two (2) discharge augers. 560 mm diameter x 5,995 mm Long. Driven by 1.5 kW motor, 80 rpm. Dryer is equipped with stainless steel hood. Hydraulic bearing lube system. Mfg. 2012.

Stock# 48917003

Used- GMF Gouda T 15/40 KD Double Drum Dryer, 1508 MM (59.37") Diameter X 4000 MM (157.48") Face. Cast Iron Rolls.Not Chrome Plated. 204 square feet per drum / 408 square foot total area. Drums rated 8.5 bar (123 psi) at 191 degrees C. MAWP 12 bar. Drum speed 1.5-15 rpm. 18.5 KW drive. Two (2) discharge augers. 560 mm diameter x 5,995 mm Long. Driven by 1.5 kW motor, 80 rpm. Dryer is equipped with stainless steel hood. Hydraulic bearing lube system. Mfg. 2012.

Stock# 48917004

Used- GMF Gouda T 15/40 KD Double Drum Dryer, 1508 MM (59.37") Diameter X 4000 MM (157.48") Face. Cast Iron Rolls.Not Chrome Plated. 204 square feet per drum / 408 square foot total area. Drums rated 8.5 bar (123 psi) at 191 degrees C. MAWP 12 bar. Drum speed 1.5-15 rpm. 18.5 KW drive. Two (2) discharge augers. 560 mm diameter x 5,995 mm Long. Driven by 1.5 kW motor, 80 rpm. Dryer is equipped with stainless steel hood. Hydraulic bearing lube system. Mfg. 2012.

Stock# 14191060

Used- 60" Diameter Goslin Birmingham Chrome Plated Drum Flaker. 5' diameter x 7', 10 hp ex-proof varidrive with 3 to 1 speed variation. 125 rpm maximum. Available with unused spare drum. Previous use: maleic anhydride.

Stock# 46702004

Used- GMF Gouda Single Drum K Flaker, Type K17.5/36, Approximate Cooling Surface 215 Square Feet. Approximately 68.90" (1750mm) Diameter x 141.7323" (3600mm) face cored chrome plated carbon steel drum. Includes (1) knife scraper with blade, end drum scrapers, manually adjustable. Hydraulically driven by a approximate 30 hp, 3/60/230/460 volt, 1160 rpm motor, Rexroth Hydraulic unit. Top fume hood with (2) 16", (2) 4" openings. Jacketed 304 stainless steel trough with (4) side access doors. Mounted on a carbon steel frame. Includes discharge conveyor, driven by a 3 hp, 1750 rpm gear motor, 25.6 to 1 ratio.

Stock# 46702005

Used- GMF Gouda Single Drum K Flaker, Type K17.5/36, Approximate Cooling Surface 215 Square Feet. Approximately 68.90" (1750mm) Diameter x 141.7323" (3600mm) face cored chrome plated carbon steel drum. Includes (1) knife scraper with blade, end drum scrapers, manually adjustable. Hydraulically driven by a approximate 30 hp, 3/60/230/460 volt, 1160 rpm motor, Rexroth Hydraulic unit. Bolt-on top fume hood with (2) 16", (2) 4" openings. Jacketed 304 stainless steel trough with (4) side access doors. Mounted on a carbon steel frame. Includes discharge conveyor, approximate trough 258" long x 15" wide x 16" deep, 14" diameter x 256" long screw on 4" diameter shaft. Machine # K:186/101R DS 176, Built 1994.

Stock# 46702003

Used- GMF Gouda Single Drum K Flaker, Type K17.5/36, Approximate Cooling Surface 215 Square Feet. Approximately 68.90" (1750mm) Diameter x 141.7323" (3600mm) face cored chrome plated carbon steel drum. Includes (1) knife scraper with blade, end drum scrapers, manually adjustable. Hydraulically driven by a approximate 30 hp, 3/60/230/460 volt, 1160 rpm motor, Rexroth Hydraulic unit. Bolt-on top fume hood with (2) 16", (2) 4" openings. Jacketed 304 stainless steel trough with (4) side access doors, rated 174 psi (12 Bar) at 375.8 degrees F (191 degrees C). Mounted on a carbon steel frame. Includes discharge conveyor, approximate trough 148" long x 14-3/4" wide x 16" deep, 14" diameter x 148" long screw on 4" diameter shaft. Machine# K196:118R BR 193, Built 1996.
