Used 6600 Gallon Insulated ISO Tank Container – Stainless Steel | Heating Coil | 4 Bar MAWP | Built 2008

Manufacturer Information:

• Type: ISO Tank Container

• Capacity: Approx. 6600 Gallons (24,930 Liters)

• Construction: Stainless Steel Tank

• Frame: Carbon Steel ISO Frame (20 ft standard)

• Year Built: 2008

• Condition: Used

Description:

This Used Insulated ISO Tank Container, built in 2008, is a horizontal 6600-gallon (24,930-liter) stainless steel vessel, mounted in a standard 20’ carbon steel ISO frame. Designed for liquid storage and transport, it features bottom discharge, integrated heating coil, and is built for both high-pressure and extreme temperature conditions. With a Maximum Allowable Working Pressure (MAWP) of 4 bar, test pressure of 6 bar, and a temperature range from -40°C to 130°C (-40°F to 266°F), this unit is ideal for a wide range of industrial liquid handling applications.

Specifications:

• Tank Type: ISO Intermodal Tank Container

• Orientation: Horizontal

• Capacity: 24,930 liters / 6600 gallons (approx.)

• Material: Stainless Steel (Tank)

• Insulation: Yes

• Heating Coil: Integrated

• Discharge: Bottom Discharge

• MAWP: 4 bar (58 psi)

• External Design Pressure: 0.41 bar (6 psi)

• Test Pressure: 6 bar (87 psi)

• Temperature Rating:

  • Minimum: -40°C / -40°F

  • Maximum: 130°C / 266°F

• Frame Dimensions:

  • Length: 20 feet

  • Width: 8 feet

  • Height: 8.5 feet

• Frame Material: Carbon Steel ISO Frame

• Build Year: 2008

Features:

• Fully insulated stainless steel tank for temperature-sensitive liquids

• Heating coil for viscosity control and thermal regulation

• Bottom discharge for efficient unloading

• Designed for road, rail, or sea transport

• Carbon steel frame meets ISO intermodal standards

• Durable for high-pressure and high/low temperature operation

• Excellent for chemical, food-grade, or industrial liquid storage

• Suitable for mobile or static use in process environments

Applications:

• Transport and storage of bulk chemicals

• Food-grade liquid handling (oils, syrups, etc.)

• Petroleum and lubricant storage

• Heat-sensitive material transfer (glycerin, latex, adhesives)

• Marine or rail intermodal transport

• Pharmaceutical or cosmetic fluid logistics

• Agricultural liquid fertilizers and additives

• Water or brine storage in industrial settings

• Off-site batching or blending applications

• Energy or oilfield liquid chemical supply

What might this be used for?

• Storing and transporting temperature-sensitive chemicals or food-grade liquids

• Integrating into a modular liquid handling system for mobile operations

• Heat-assisted storage of high-viscosity materials (e.g., molasses, paraffin)

• Replacing standard tanks with insulated and pressure-rated solutions

• Providing onsite liquid storage for process or batch production

• Transporting bulk liquids to remote locations via intermodal systems

• Handling fluids in seasonal environments with freezing risk

• Utilizing for field operations in energy, agriculture, or chemical processing

• Serving as backup liquid storage with controlled temperature parameters

• Enhancing liquid delivery with heating and pressure resistance features
