Used De Dietrich 2030L Glass-Lined Reactor – 536 Gallon, 3009 Blue Glass, Vertical

Manufacturer Information:

• Brand: De Dietrich
• Type: Glass-Lined Reactor
• Model: 3009 Blue Glass
• Capacity: 2030 Liters (536.43 Gallons)

Description:

This used De Dietrich 2030L (536.43 Gallon) Glass-Lined Reactor is a high-performance vessel, ideal for chemical, pharmaceutical, and industrial processing applications requiring corrosion-resistant glass lining.

Constructed with 3009 blue glass lining, this reactor ensures excellent resistance to acidic and corrosive environments, making it suitable for highly reactive chemical processing. The vertical orientation with dished top and bottom provides uniform mixing and efficient processing.

The reactor is internally rated for -1 to 6 bar (-14.5 to 87 psi) at 30 to 200°C (-22 to 392°F), ensuring safe operation in demanding conditions. The carbon steel jacket is rated -1/6 bar (-14.5 to 87 psi) at 30 to 200°C (-22 to 392°F), allowing precise thermal regulation for controlled reactions.

Key features include:

• Fin Baffle for enhanced mixing and heat transfer
• Multiple Top Openings:
  • (1) Approximate 30”
  • (3) 4”
  • (2) 8”
• 4” Bottom Outlet for controlled product discharge
• Side Mounting Ring for stability and secure installation

Serial # 57364

Specifications:

• Capacity: 2030 Liters (536.43 Gallons)
• Construction: 3009 Blue Glass-Lined, Carbon Steel Jacket
• Orientation: Vertical
• Vessel Dimensions: 54” Diameter x 44” Straight Side
• Ends: Dished Top & Bottom
• Internal Pressure Rating: -1 to 6 bar (-14.5 to 87 psi)
• Jacket Pressure Rating: -1 to 6 bar (-14.5 to 87 psi)
• Temperature Range: 30 to 200°C (-22 to 392°F)
• Baffle: (1) Fin Baffle
• Openings:
  • (1) Approximate 30”
  • (3) 4”
  • (2) 8”
• Bottom Outlet: 4”
• Mounting: Side Mounting Ring
• Serial #: 57364

Applications:

• Pharmaceutical & Biotech – Synthesis of active ingredients, fine chemicals, and bioprocessing
• Chemical Processing – Corrosion-resistant reactor for acids, solvents, and hazardous materials
• Petrochemical & Industrial Manufacturing – Reaction vessel for high-temperature processing
• Food & Beverage – Processing of food-grade chemicals, additives, and ingredients
• Research & Development – Laboratory and pilot plant production of specialty compounds

What Products Would This Be Used For?

• API (Active Pharmaceutical Ingredient) production
• Specialty chemical synthesis
• Corrosive acid and solvent reactions
• Polymer and resin manufacturing
• High-temperature industrial formulations
