Stock No.:
88940Industrial Vacuum Belt Filter - Pannevis RT, 316 SS & Polypropylene
Used- Pannevis Horizontal Vacuum Belt Filter, Type RT, 316 Stainless Steel/Polypropylene Construction. Approximate 5.3 square meter filtration area. Filter 960 x 5600mm. Vacuum tray. Driven by a .75 kw, 3/50/380 volt varispeed motor. Mounted on a carbon steel frame. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.
MFR: Pannevis
Stock No.:
54687104Used 370 square feet Isotherm 304 stainless steel shell and tube heat exchanger. Heat exchanger built by Isotherm of Arlington, TX in 2000. Model number IX-1215L for non-lethal, non-corrosive servic...
Used-370 square feet Isotherm 304 stainless steel shell and tube heat exchanger. Heat exchanger built by Isotherm of Arlington, TX in 2000. Model number IX-1215L for non-lethal, non-corrosive service. Serial number 00038X. National Board number 66. Shell MAWP is 100 PSI @200 degree F. Tube MAWP is 250 PSI @ 200 degee F. Unit has 154- 16 gauge SA249-TP304 straight tubes 14'- 8 5/8" long. Shell is 12-3/4" diameter times 14'-8 5/8" long of SA312-TP304. Both heads are 304 stainless steel. Shell side nozzles are two 4" RFSO flanges, one 1" threaded coupling, and one 3/4" threaded coupling. Tube side nozzles are two 3" tubes, two 1-1/4" tubes and two 1/4" couplings.The tube side tubes are brazed into the head and appear to be copper. Fittings or attachment to piping required. Unit has two saddle supports.
Stock No.:
10715053In STOCK AND New- Paul O. Abbe, Model RB-375 Ribbon Blender
NEW & IN STOCK- Paul O. Abbe, Model RB-375 Ribbon Blender.In -Stock . 375 Cubic Foot working capacity. 441 Cubic Foot total volume. Type 304 stainless steel polished. Food grade. All stainless steel construction. Trough dimensions: Approximately 67.7" wide x 157.5" long x 78.8" deep. Internal double spiral ribbon. Packing glands and pillow block bearings. 75 hp SEW Euro drive hollow bore design. 230/460 volt, 1775 rpm, 3/60 with approximately output 20 rpm. Top cover with hold down clamps and limit switch. Center Loading cover with welded safety grate, 30" wide x 50" long. Approximate 5.5" wide x 27.6" flush air operated plug valve. Discharge housing is approximate 20.5" wide x 36.2" long. Approximately 4" discharge height. Approximate weight 20,944 pounds. Approximate overall dimensions: 91.9" wide x 237.1" long x 104.7" high. Controls are available upon request.
MFR: Paul O Abbe
Stock No.:
54697002Used CMS 38.3 Sq. Ft. 316L Stainless Steel Shell and Tube Heat Exchanger
Used CMS Heat Transfer Division 38.3 Square Foot 316L Stainless Steel Horizontal Shell And Tube Heat Exchanger With 160 PSI Pressure Rating. Industrial shell and tube heat exchanger designed for liquid-to-liquid heat transfer, process cooling and industrial temperature control applications. Features approximately 38.3 square feet of heat transfer surface area with (22) straight tubes constructed of 316L stainless steel, each measuring 3/4" in diameter. Shell and tubes are constructed of 316L stainless steel and rated for a maximum allowable working pressure of 160 psi and full vacuum at operating temperatures ranging from -20 F to 400 F. Process connections include (2) 3" shell-side openings, (2) 3" tube-side openings and (4) 3/4" auxiliary nozzles. Originally designed as an industrial cooler, Equipment Tag E-600. Manufactured by CMS Heat Transfer Division, Inc., Bohemia, New York, for Cincinnati Heat Exchangers. Serial #3194.1. National Board #2247. Possible applications include liquid-to-liquid cooling, industrial process temperature control, circulating water cooling, lubricating oil cooling, hydraulic fluid cooling, chemical process cooling, heat recovery and thermal management of other compatible industrial liquids.
Stock No.:
54154001Used – 3,800 Gallon Stainless Steel Vertical Storage Tank – 316 SS, Flat Top, Di
Used- Stainless Steel Vertical Storage Tank, Approximately 3800 Gallon Capacity, 316 Stainless Steel. Flat top, Dish bottom. Approximately 94" diameter x 128" straight side. Openings Top" (3) 2" 23" x 23" manway with cover. 2" Center bottom outlet, approximate 9" discharge height. Mounted on (4) Carbon steel legs.
Stock No.:
54393001Unused GF Corporation MDL-050CM Micro Mist Spray Dryer – 3 kg/h Stainless Steel Lab Spray Drying System (2021)
Unused GF Corporation Micro Mist Spray Dryer, Model MDL-050CM. Stainless steel construction with 3 kg/hour (6.6 lbs/hour) evaporation capacity at 200 C (392 F) inlet and 60 C (140 F) outlet temperatures. Approx. 39" diameter x 40" straight side drying chamber with four-fluid nozzle, co-current airflow, cyclone and filter bag collection, 50 ml/min liquid feed pump, touch screen controls, and 5 kW heater. 3 phase, 200V electrical. Built 2021. Possible applications include spray drying liquid solutions and suspensions into fine powders for food, pharmaceutical, chemical, ceramic, and specialty material applications
Stock No.:
13140018Used Approximately 3900 Square Foot Kennedy Tank & Manufacturing Co Heat Exchanger
Used- Kennedy Tank & Manufacturing Co Horizontal Heat Exchanger. 304 Stainless shell and tube side. Overall dimensions: 44" diameter x 20'6" long. Shell rated 50 at 250 degree F and tubes rated 38/FV at 250 degree F. Built 1997. Mounted on short saddles. Fittings: top (1) 4", (2) 6"; shell vent/drain (2) 2"; bottom (1) 24" and (1) 6". Tubes are 15' face to face length with (990) 1" tubes. Included bolt-on dished heads. Approximately 3900 Square Foot
MFR: Kennedy
Stock No.:
10131011Used AMK Double Arm Mixer VIU Strength Class IV – 1500L Capacity, 316SS, 135HP, Tilt Discharge, Built 2005
Used- AMK Double Arm Mixer, Type VIU-Strength Class IV. 316 (V4A) Stainless Steel on product contact parts. Max working capacity 396.8 gallon (1500 liter). Z-blades. Double jacketed bowl and not rated vacuum. Working temp 68-392 deg F (20-200 deg C). Hydraulic tilt discharge mechanism. top cover. Mounted on carbon steel support frame. New year 2005. Previous used in a pigment application. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.
MFR: AMK
Stock No.:
11690031Used Tetra Pak (Scanima) STM-1250V Aseptic Mixing Reactor | 1,500L High Shear Vacuum Vessel
Used- Tetrapak (Scanima) 1,500 Liters (396 Gallon) 316 Stainless Steel Vacuum and Pressure Jacketed Aseptic High Shear Mixing Reactor, Model STM-1250V. The vessel is rated full vacuum /45 PSI internal pressure, and is jacketed for 75 PSI maximum pressure, maximum jacket temperature is 150 Degrees C. Bottom entering high shear agitator driven by a 50 HP (3/60/460V) motor. Includes a 2" Pneumatic discharge valve and 2" recirculation valve. Includes a control panel with VFD, a pneumatic panel and an operator PC station. Built 2009.
MFR: TetraPak
Stock No.:
10131007Used Kurimoto Double Arm Sigma Blade Mixer | 1500L (396.8 Gal) | 304 SS | Jacketed | EPS Application
Used Kurimoto Double Arm Sigma Blade Mixer | 1500L (396.8 Gal) | 304 SS | Jacketed | EPS Application. 304 (V2A-1.4301) Stainless Steel on product contact parts. Working capacity 396.8 gallon (1500 liter). 304 stainless steel jacket bowl with counterweights. Sigma style blades. Last used in an EPS (super absorption) application. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.
MFR: Kurimoto Osaka
Stock No.:
10131008Heavy-Duty 1500L Kurimoto Sigma Blade Mixer – 304 SS, Jacketed, Double Arm Kneader
Heavy-Duty 1500L Kurimoto Sigma Blade Mixer 304 SS, Jacketed, Double Arm Kneader. 304 (V2A-1.4301) Stainless Steel on product contact parts. Working capacity 396.8 gallon (1500 liter). 304 stainless steel jacket bowl with counterweights. Sigma style blades. Last used in an EPS (super absorption) application. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.
MFR: Kurimoto Osaka
