Used Multivac Tray Sealing Machine - 500mm Film Width, Flexible Packaging

Used- Multivac Stainless Steel Automatic Food Tray Sealer, Model T-300. Capable of speeds from 12 - 30 packs per minute (6 - 10 cycles/min). Tray former: 420mm x 300mm, divisible up to three uses. Tray height: up to 110mm. Has Busch Model R5-RA 0100 vacuum system. Top film web width (flexible): up to 500mm, max diameter of film roll 350mm. Dome application / Skin, has gas flush. Sew servo drive. Multivac / Beckhoff HMI. Includes Koolant Koolers chiller, model JHI-1000-M. Was originally set up to run trays of ground beef (not included). Mounted on casters. 3/60/220V.

MFR: Multivac

Used Multivac R230 Horizontal Roll Stock Thermoformer – 16.5" Film Width, 130mm Depth

Used- Multivac Model R230 Horizontal Stainless Steel Roll Stock Thermoformer. Capable of speeds from 8 - 10 cycles per minute. Film width approximate 16.5". Approximate 130mm max forming depth.

MFR: Multivac

Used Multivac R-145 Thermoforming Machine – 420mm Web, 4-Up Mold, Inkjet Printer, Medical Packaging, 2009

Used- Multivac Roll-Stock Thermoforming Machine, Model R-145. Includes Bel-Mark Thermal Ink Jet Printer, Model MLB. 420mm web width. 360mm advance, 22 (4 up) mold plate with approximately 6? wide x 7? long pockets, trim wind-up system, 220V/3PH/60HZ.Stainless steel construction, last used in medical packaging. Built 2009.

MFR: Multivac

Unused Multivac R 245 Rollstock Packaging Machine – 2021 Medical-Grade

Unused Multivac R 245 Fully Automatic Stainless Steel Horizontal Form, Fill and Seal Rollstock Packaging Machine. Hygienic design (IP 65). Machine stands in Clean Design GMP. Format dimensions: Web width 360mm, maximum width is 560mm; Cutoff length 241mm, maximum length is 500mm; Forming depth 70mm, Height max 100mm. Operating range: X Axis 800mm; Z Axis 200mm. Cycle Rate: ca. 35 standard cycles/min (depending on load and distance). Product weight maximum 2500 g. Packaging Material: Bottom web (rigid), Type: PETG, width 362mm, tolerance +2mm, thickness 30mil. Top web (flexible), Type: Tyvek 1059B, width 355mm, tolerance +1mm, thickness 4mil. Busch SV 1025 vacuum pump. Bell-Mark 8.3" EasyPrint MLP Electronic Thermal Transfer Traversing Printer. Optical inspection system, inline machine operation integrated into the machine. Photoelectric print registration. Suction gripper for converging 1 lane, 6 channel. PT 100 temperature sensors, with Multivac plug system. FS 08 cross cutting steel rule punch lower part, FS 87 cross cutting steel rule punch upper part. Trim removal, RSW20 edge trim winder. Machine control IPC 06, operating system Windows Embedded, high temperature, vibration, and EMC stability. 12" touch screen terminal, user interface HMI 2.0. Discharge conveyor with flat top chain, 1700mm long and 400mm wide, single track with frequency converter for speed controlled package discharge. Dimplex Model JHI-1500-DM recirculating water chiller. Machine dimensions: approximate length 9,217mm, approximate width 1,042mm, approximate height 2,350mm. 3/60/480V. Serial # 295976. New in 2021. Was designed to package medical supplies. Still in original crating.

MFR: Multivac

Automatic Capsule Filler – Najing Hanyoo NJP-2000C, Enclosed, 2000 Capsules/Min

Used- Najing Hanyoo Encapsulation Machine; Model NJP-2000C; Automatic Capsule Filling Machine 1).This machine absorbs advantages of other similar capsule filling machine and is self-designed and researched advanced empty capsule filling machine. 2).Adopt forged surface cam transmission structure and there is no spring in the transmission part. 3).Adopt full closed workstation rotating plate with automatic lubricating system. 4).Adopt 10.4inch colorful LCD screen to auto-alarm and auto-stop under the conditions of lacking capsules, lacking prwder, vacuum failure, dust absorption failure or the machine gate loosen. 5). Adopt import main engine, electrical components, bearing and high-precision periodical indexing box(the space between input shaft and output shaft increases from 83MM to 145MM)to increase the stability of control system and drive system. 6).Patented modularized punch holder mechanism and double pitch feed copper to facilitate dismounting and accurate positioning. 7).It is unnecessary to dismantle die molds to clean or change. 8).Machine and electric parts are separated,which is easy to clean and keep safe. 9).This machine has been awarded more than 10 items of Chinese patents. Remarks: cGMP design with emphasis in powder dust handling: Enclosed main turn table avoid dust getting into mechanical parts. Automatic control for capsule and powder supply. PLC control for reliable operation. Touch Screen HMI, featuring user friendly controls: production counter, manual / automatic / parameter setup modes, alarms. Precision capsule segments and dosing disk minimize adjustments following parts changeover. SS 304 stainless steel frames and transparent safety interlock guard.

Nalbach R1-S3-105 LH Bottle Descrambler | 35 Cu Ft Hopper | Used Packaging Equipment

Used Nalbach Necosort R1-S3-105 LH Bottle Descrambler. Previously used for 16, 24, 32, and 48 ounce bottles. Bottle shape: Round, square, oval, rectangle. Production output rate: 550 bottles per minute. Integral bulk hopper capacity: 35 cubic feet. Control panel for descrambler and conveyor. Includes: 40' long conveyor with two blowers, controlled by Descrambler. Power supply: 3/60/480 volt, 35 amp. built 2011.

MFR: Nalbach

Industrial 300kg Basket Centrifuge for Sale – Nanjing Kingreat PPTD-300, 431 G

Used- Nanjing Kingreat Basket Centrifuge, Model PPTD-300. 300kg capacity; 1200mm basket diameter; 250L volume; 431 G-force; 800 RPM; Top discharge; 11 kW (approx. 15 HP) power. Overall size: 2300mm x 1700mm x 1300mm. Without control panel.

Used Nash CL 2002 Vacuum Pump | Industrial Liquid Ring Vacuum Pump

Used Nash CL 2002 Vacuum Pump | Industrial Liquid Ring Vacuum Pump. This vacuum pump has an estimated cfm of 2000 at 24" Hg. Unit has 6" flanged inlets and 5" flanged outlets. Cast iron construction. The test number is ML10166 and the job number is ML10166. Motor is not included. This unit was a spare. Appears to be in good condition.

MFR: Nash

Used Nash CL2002 Liquid Ring Vacuum Pump System | 100 HP Industrial Vacuum Package

Used Nash CL2002 Liquid Ring Vacuum Pump System | 100 HP Industrial Vacuum Package. The test number is ML09216 and the job number is ML10325. This Vacuum Pump has an estimated cfm of 2000 at 24" Hg. Unit has an 8" flanged inlet. The 75 gal separator tank has a 6" diameter flanged port on the top, a 3" diameter flanged port on the bottom, and a 15" by 15" access port on the side. Pump has a carbon steel base. Is driven by a 100 hp 1780 rpm motor. Requires 230/460 vac 3 phase electrical supply. Pump turns freely. Appears to be in good condition. The concrete has been removed from the base.

MFR: Nash

Used Nash SC7 SC Liquid Ring Vacuum Pump – 60 HP, Carbon Steel, Frame-Mounted

Used- Nash SC Liquid Ring Vacuum Pump, Model SC7, Carbon Steel. Approximate 500 to 735 cfm. Driven by 60 hp, 3/60/230/460 volt, 1775 rpm motor. Max 880 rpm. Includes silencer. Mounted on frame. Test# 94E9919.

MFR: Nash

Used Nash SC7 SC Liquid Ring Vacuum Pump – 500-735 CFM, 60 HP

Used- Nash Model SC7 SC Liquid Ring Vacuum Pump, Carbon Steel. Approximate 500 to 735 cfm. Driven by 60 hp, 3/60/230/460 volt, 1775 rpm motor. Max 880 rpm. Includes silencer. Mounted on frame. Test# 94E9920.

MFR: Nash

Industrial Liquid Ring Vacuum Pump - Nash CL Series, 3/60/230/460V

Used- Nash CL Series Liquid Ring Vacuum Pump, Model CL-703/4. Approximate 500 to 650 cfm. Driven by a 75hp, 3/60/230/460 volt, 1185 rpm motor. Approximate 4" inlet, 3" outlet. Mounted on a base plate.
