24" x 16" Davis Standard Pilot/Laboratory Size Horizontal Sheet Line

Used- 16" Davis Standard Pilot/Laboratory Size Horizontal Sheet Line. Consisting of: (2) 1" Killion/Davis Standard pedestal style Co-Extruders, each 24/1 L/D, driven by 3HP AC motors with individual temperature control panels, grooved feed throats, general purpose 3:1 barrier type screws and air cooled barrels. (1) 1.25" Killion/Davis Standard primary 30/1 L/D extruder, driven by a 15HP AC motor, grooved feed throat, general purpose 3:1 barrier type screw, individual temperature control panel, gear pump, and air cooled barrel, (4) spare screws. (1) Cloeren Co Ex Block with multiple inserts for co extrusion. Inserts include: AAAAA, BBAAA, CBAAA, AABAA, CAAAB, CCCCC, CBABC, BAAAB, ABCAA configurations, built 2006. (1) 14" Cloeren sheet die, center back entrance, mounted for use in downward direction, serial# A06-1782-02, built 2006. (1) Davis Standard horizontal sheet chill roll stack with (3) 16" wide x 24" OD rolls. Each roll driven by an individual gear motors, built into frame hydraulic roll loading. Rotary unions for roll cooling/heating with Conair model TC1 stand-alone temperature control. Unit can be ran as a cast unit or sheet take-off, with pull rolls. Includes (2) matt finished rolls, (1) silicon covered roll and (4) chrome rolls. Laboratory use only.
