Used-Hosokawa Model ACM300 Vertical Air Classifier System

Used-Hosokawa Model ACM300 Vertical Air Classifier System, with Mill, Blower, Dust Collector, Rotary AirLock and Screw feeder. System consists of Structural steel base and stand legs, Cast iron / carbon steel construction, Gravity style feed assembly consisting of a flanged nozzle for rotary valve feeder connected to the mill. grinding chamber feed duct, Rotor disc with eight (8) hammers with tungsten carbide tipping, Rotor disc with AR400 wear replaceable wear plate. Steel 24 LONG radial blade classifier wheel with TC coating. Includes one (1) spare 24 long radial blade SHORT classifier wheel with TC coating per mill to produce 50 MESH product specification, Multiple deflector type grinding liners, NiHard construction, Standard dispersion ring, T-1 Shroud ring assembly with baffles, Automatic oil lube system: Type Bijur, Body safety interlock switch, 350 HP, 460V/3Ph/60Hz Main Grinder Drive motor, inverter-duty, TEFC. 50 HP, 460V/3Ph/60Hz, 1800 RPM, TEFC, inverter-duty classifier motor. Includes (2) Blower's, (2) Donaldson Dust Collector, Volumetric Screw Feeder, Rotary Air lock, Micron MS-4H air classifier,
