Used Cooling Towers
Below is Aaron's inventory of unused and used cooling towers.
Stock No.:
53852001Used BAC Cooling Tower – Model XES3E-1222-10L-2, 1033 Nominal Tons, 3100 GPM
Used BAC Cooling Tower, Model XES3E-1222-10L-2, rated at approximately 1,033 nominal tons with a 3,100 GPM flow rate, cooling water from 95 F to 85 F at 78 F entering air wet bulb temperature. Unit features a stainless steel fan guard, stainless steel internal walkway, and 4' ladder with cage. Equipped with (2) 15 HP, 3-phase, 60 Hz, 460V fan motors. Built in 2018.
MFR: BAC
Stock No.:
54607004Used SPX Marley NC8403P 2-Cell Crossflow Cooling Tower – 329 Nominal Tons with Dual 84" Fans
Used- SPX Marley 2-Cell Crossflow Cooling Tower, Model NC8403P. Approximate 329 Nominal Tons (363 with VR Cylinder). 8" diameter inlet/outlet. (2) 84" fans. Driven by 15hp motors. Serial# 10103272-A1-NC8403GG-15. Built 2015.
MFR: SPX
Stock No.:
54334001Used Marley Double Flow Cooling Tower | 450 Ton Industrial Cooling System (Model MHF7113)
Used- 450 Ton Marley Double Flow Cooling Tower Model MHF7113. 410-746 ton cooling capacity, based on 3gpm/ton at 95 f hot water 85 F cold water 78 F wet bulb configuration. Built 2016. Dimensions 13'-11" long x 25'-10" wide x 22' tall 41,310lbs.
MFR: Marley
Stock No.:
54391001Used EVAPCO ATWB 4-3E9 Z Closed Circuit Cooling Tower – 42 Ton Process Fluid Cooler (2018)
Used- EVAPCO Process Cooling Tower, Model ATWB 4-3E9 Z. Approximately 42 Nominal Tons. 131 GPM flow rate. Closed Circuit. (2) 2 HP fans, approximate 18,110 CFM. 100 degrees F entering fluid temperature, 90 degrees F leaving fluid temp, 78 degrees F wet-bulb temperature. Stainless steel basin. Built 2018.
MFR: Evapco
Stock No.:
13147001Used BAC Baltimore Aircoil 3455A-MM Cooling Tower – 455 Tons | 20 HP Fan | 1000 GPM | Heavy-Duty Steel Construction
Used- Baltimore Aircoil 455 Ton Cooling Tower, Model Number 3455A-MM, Open Loop. (2) 8,000 watt heaters. 20 HP totally enclosed fan. 460 Volt. 3 phase. All steel construction. 8? water inlet and outlet. OAD: 245"L x 122"W x 136'H . 1000 GPM. Approx. 15,000 lbs.
MFR: Baltimore Air Coil
Stock No.:
54219002Tower Tech TTXL-061975 FRP Cooling Tower – Open Circuit, Direct Drive, 1800 GPM
Tower Tech Cooling Tower, Model TTXL-061975, Open Circuit Design / Modular fiberglass cooling tower rated for approximately 600 tons of cooling capacity. It features a fiberglass reinforced plastic (FRP) casing and basin, PVC fill media, and drift eliminators. Unit has direct-drive axial fans with a hot-water spray distribution system. Typical operating conditions are 95F inlet water, 85F outlet water, and 78F wet-bulb ambient, with a flow rate of about 1,800 GPM. The tower has removable louvers, access panels, stainless steel hardware. Serial# 2008031-02. Built 2008.
MFR: Tower Tech
Stock No.:
53642001(8) Evapco Eco-ATWB 24-4N20 Closed Circuit Cooling Towers. Approximately 600 ton
Used- Lot of (8) Evapco Eco-ATWB 24-4N20 Closed Circuit Cooling Towers. Approximately 600 ton each. Each approximate 2,800 GPM. (2) 40hp fans, approximate 281,190 CFM. Coil volume 5,107 liters (1349 gallon). (2) 40HP fans. Setup as (2) cell units. Seller would like to sell all 8 units at one time, however, will accept offers. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.
MFR: Evapco
Stock No.:
51258012Used SPX Marley NC8409U Crossflow Cooling Tower – 790 Ton/Cell | 2018 Build | 4-Cell Industrial System
Used SPX Marley NC8409U crossflow cooling tower system featuring a 4-cell industrial configuration with an approximate combined cooling capacity of 790 tons. Each cell is rated for approximately 1,650 GPM, providing a total system flow of 6,600 GPM. Designed for cooling water from 109.0 F hot water temperature to 85.0 F cold water temperature with a 76.0 F entering wet bulb temperature. Each cell is equipped with a 12' diameter, 5-blade fan driven by a 50 HP motor operating at 1,800 RPM with 60 Hz, 230/460V electrical service. Built in 2018.
MFR: SPX
Stock No.:
54531002BAC Baltimore AirCoil 33620-2TR Cooling Tower, 3,600 USGPM
Used BAC Baltimore AirCoil 3000 Series Cooling Tower, Model 33620-2TR. 3,600 USGPM of water from 95 degrees F to 85 degrees F entering air wet bulb temperature and 6.45 psi fluid pressure drop. Fan driven by 50HP, 3/60/460 volt, 1800rpm motor. Galvanized cold water basin with 4" connections. 34" x 35" Access doors. Serial # U0021209. Built 2000.
Stock No.:
54531003Used BAC Baltimore AirCoil 3000 Series Cooling Tower, Model 33620-2TR
Used-BAC Series 3000 Cooling Tower. Heavy Gauge Panel Construction. 4 in Cold Water Connections, Connections Less Than 4 in Are Provided with Male Pipe Threads. Casing Constructed of Fiberglass-Reinforced Polyester Panels. hinged 34 in x 35 in Access Doors. Wave Formed Air Inlet Louvers. (2) 150# Stud Circle Hoy Water Inlet Connections Per Cell on Top of Unit. Gravity Type Hot Water Basins. BACross Wet Deck Surface and Drift Eliminators Formed From PVC. Axial Flow Aluminum Fans. Heavy Gauge Fan Guards. 3,600 USGPM of Water From 95 Degrees F to 85 Degrees F with 78 Degrees F Entering Air Wet Bulb Temperature and 6.45 PSI Fluid Pressure Drop. (1) 50 HP 1800 RPM TEFC Fan Motor. Baltibond Corrosion Protection System. Ladder and Safety Railing. Dual Top Inlet Connections with Flow Control Valves. Extended Lube Lines.
