Used Paul Mueller Company, 15,700 Gallon Food Grade Storage Tank

Used Paul Mueller Company 15,700 Gallon Food Grade Storage Tank. Approximate capacity of 15,700 gallons. Constructed with a 12' outside diameter x 17' 5/8" straight side and dished top and bottom heads. Equipped with a 3" flanged center bottom outlet for complete product drainage. Carbon steel painted exterior with skirt-mounted design. Top head features an 18" diameter manway with cover and multiple flanged process connections. Overall height is approximately 23' 6". Estimated tank weight is approximately 11,000 lbs. Previously used in brewery service. Suitable for food, beverage, brewery, and other sanitary storage applications.

MFR: Paul Mueller

Used DCI 15,000 Gallon 316L Stainless Steel Jacketed Sanitary Mix Tank / Fermenter / Reactor with 100 HP Agitator

Used DCI 15,000 Gallon 316L Stainless Steel Jacketed Sanitary Mix Tank / Fermenter / Reactor with 100 HP Agitator. Internal Rated 35 PSI/Full Vacuum at 358 degrees F. Jacket rated 135 PSI/FV at 358 degrees F. 11' internal diameter x 20'9" T/T. Approx. 31'3" overall height. Top mounted 100 HP, 460 volt mixer. with 15-142 rpm output speed (requires VFD). NB #11705. Previously used in Sanitary Food, Nutrition Ingredients Processing Plant.

MFR: DCI

Used 15,000 Gallon Agra Industries Stainless Steel Tank | 304 SS | Single Wall

Used- 15,000 Gallon (approx.) Agra Industries Stainless Steel Tank. 304 Stainless Steel. Approximate 192" diameter x 16' straight side. Single Wall. Built 2011.

15,000 Gallon Stainless Steel Storage Tank by Letco Incorporated

Used Letco Incorporated Approximate 15,000 Gallon Stainless Steel Tank, Approximate 144" diameter x 216" straight side, dished top & bottom. Mounted on (6) steel legs (2 legs have been cut). Serial# 898-1.

MFR: Letco

Pre-Owned Rapid 1521 Lab Granulator – 2.2?kW, 3-Phase, Compact R&D Granulator

Used Rapid 1521 Lab Granulator. Capacity 88 lbs/hr. (40 kgs/hr.). 8.2" (210 mm) x 5.85" (150 mm) inlet. Rotor incl. 2 x Bed knives, 3x3 Rotating knives driven by a 2.2 KW-400 Volt/50 Cycle/ 3 Ph. Rotor speed 295 RPM. Serial # 2501761, New year 1996. Previously use in an R&D application. Over all dimensions: 18.5" (475 mm) long x 14" (360 mm) width x 53.4" (1370 mm) high. Weight 385 lbs (175 kgs). Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.

MFR: Rapid

Used Krones Thermowave TL 500 FBXV Plate Heat Exchanger – 1,534 Sq. Ft., 145 PSI, Stainless Steel

Used- Krones Thermowave Plate Heat Exchanger, Approximate 1,534 Square Feet, Type TL 500 FBXV. (10) Chambers each rated 10 bar (145 psi) at 100 degrees C. (212 F.). (307) 254 SMO High-alloy austenitic stainless steel plates approximate 18" wide x 60" tall. Includes (2) spacers, (20) 3-1/4" inlets/outlets. Mounted on an expandable stainless steel frame. Serial# 31891. Built 2008.

MFR: Krones

Used Cummins C1540 N6C Natural Gas Generator Set – 1540 kW, QSV91G Engine, Low BTU Gas Capable, 60 Hours

Used- Cummins Generator Set, Model C1540 N6C. Rated 1540kW; 480 Volt, Driven by a Cummins Model QSV91G 91-liter natural gas engine with a low BTU system mounted on it; Has cooler, breakers, and controllers. Engine suitable for both pipeline and landfill gas. Serial# F15K840326. Built 2015. Unit has 60 test hours.

MFR: Cummins

Used Bavarian Brewery Technologies K30 Brew Tank – 42.2 BBL, 304 Stainless Steel

Used- Bavarian Brewery Technologies Brew Tank, Model K30, 42.2 Gross Volume BBL Capacity, Approximately 1540 gallon capacity, 304 Stainless Steel, Vertical. Approximately 72" diameter x 80" straight side. Dished top, flat bottom. Sidewall jacketed with 15psi max steam jacket. Openings Top: 16" manway with cover, 10", 1-1/2", Side: 5" with sight glass, 2" with sight glass, 1-1/2", 2" side bottom outlet with 6" discharge height. leg mounted. Serial# 0220.

Used Sonoma Stainless 15,420 Gallon Wine Tank | Jacketed & Insulated Stainless Steel Vessel

Used Sonoma Stainless 15,420 Gallon Wine Tank | Jacketed & Insulated Stainless Steel Vessel. Glycol jacketed. Exterior foam insulated. 239" overall height x 135" diameter. 33" high legs/tank stand. Previously used for wine storage.

Used Glacier Tanks 40 BBL Stainless Steel Brew Tank / Fermenter – Jacketed Conical Fermentation Vessel

Used Glacier Tanks 40 BBL Stainless Steel Brew Tank / Fermenter Jacketed Conical Fermentation Vessel. Total volume 1550 gallon, minimum working volume 1,240 Gallons. 304 Stainless steel. Approximately 62" diameter x 84" straight side. Dished top, Cone bottom. Dimple Sidewall and bottom cone jacket, rated approximately 14.7 psi. Openings Top: 4", 2-1/2", 2", 16" side bottom manway, Approximately 2" center bottom outlet with 13" discharge height. Mounted on (4) legs. On Carbon Steel rolling cart. Serial# GT-V-3215.

MFR: Glacier

Rubicon Shell/Tube Heat Exchanger, Model VT221B1-216V

Used- Rubicon Shell/Tube Heat Exchanger, Model VT221B1-216V. 1,554 square feet surface area; Stainless Steel; National Board #2105; Serial #3472-2; 150 psi @ 200F shell MAWP; 200/FV @ 200F tubes MAWP; carbon steel shell material; 304 stainless steel tubes material; OAD: 26" dia. x 216" long; Additional information: (577) 0.75" x 168" long 304 stainless steel tubes, vertical design. Built 2008.

MFR: Rubicon

Used GEA Niro Soavi NS3037H Homogenizer | 6,000 LPH Stainless Steel Dairy Homogenizer

Used GEA Niro Soavi NS3037H Homogenizer | 6,000 LPH Stainless Steel Dairy Homogenizer. Designed for 6000 liter (1587 US-Gallon) per hour with a max pressure of 100 BAR (1500 PSI). Single stage. Puppet Valves. 30 Kw-400volt/50cycle/3Ph motor. Incl. Oil pumping system inside the unit. Control panel mounted on unit. Overall dimensions: 2300 mm (7'5") long x 1520 mm (4'9") width x 1550 mm (5'1") high. Weight 2 tonnes. Last used in dairy application. Serial # 5162 New year 2003. Our freight specialists can assist you with door to door transportation and all customs documents needed to make the process go as smoothly as possible.

MFR: Gea-Niro
