Unused 600–1,200 SCFM Gas Chilling, Deoxygenation & Dehydration Skid – High-Methane Gas Conditioning System

Manufacturer Information

Manufacturer: PSB Industries
Year Built: 2025

This unused integrated gas-conditioning skid is engineered for high-methane gas service and combines three primary treatment stages: gas chilling/dehydration, oxygen removal, and final moisture removal using a TSA dryer. The packaged design provides a consolidated solution for conditioning methane-rich gas streams prior to downstream processing, transportation, or other suitable applications.

Description

Available for sale is an unused gas chilling, deoxygenation, and dehydration skid, built in 2025, with a rated gas flow capacity of approximately 600 to 1,200 SCFM.

Designed for high-methane gas service, the system incorporates three sequential process sections. Section 1 provides chilling and initial dehydration, cooling the gas stream to approximately 40°F. Section 2 provides deoxygenation, with a design inlet oxygen concentration of 0.4 mol% and a specified outlet oxygen concentration of less than 0.1% by volume. Section 3 utilizes a TSA (Temperature Swing Adsorption) dryer for final moisture removal, with a specified outlet moisture level of less than 7 lbs/MMSCF.

The deoxygenation/dryer portion is designed to operate at approximately 130–170 PSIG at full flow, while the chilling section can accommodate a low-pressure inlet down to approximately -4 PSIG. Vessel design pressure is 200 PSIG.

The package is designed for ambient temperatures ranging from -20°F to 100°F and incorporates a 90 kW electric trim heater and 35 kW electric regeneration heater. Electrical requirements are 3-phase, 60 Hz, 480V.

This unused skid offers an integrated solution for methane-rich gas streams requiring controlled cooling, oxygen reduction, and moisture removal.

Specifications

Typical Applications

• High-methane gas conditioning
• Renewable natural gas processing
• Biogas upgrading systems
• Landfill gas treatment
• Digester gas conditioning
• Gas dehydration
• Oxygen removal
• Moisture removal
• Pipeline gas pretreatment
• Methane recovery projects
• Gas purification systems
• Downstream gas-processing preparation

Gas Streams & Processes This System Could Be Used For

• Methane-rich gas
• Upgraded biogas
• Renewable natural gas (RNG)
• Landfill-derived methane
• Anaerobic digester gas
• Biomethane
• Recovered process gas
• Compatible fuel gas streams
• Gas streams requiring oxygen reduction
• Gas streams requiring dehydration
• Gas requiring TSA drying
• Other compatible methane-rich process gases

Actual suitability and outlet specifications depend on complete feed-gas composition, contaminants, temperature, pressure, flow rate, adsorbent/catalyst condition, utility availability, and site-specific operating requirements.

Frequently Asked Questions

• What is the flow capacity of this gas-conditioning skid? The system is designed for approximately 600 to 1,200 SCFM of high-methane gas.
• What processes are incorporated into the skid? The system combines chilling/dehydration, deoxygenation, and TSA moisture removal into a three-section gas-treatment process.
• How much oxygen can the system remove? The stated design basis is 0.4 mol% inlet oxygen, with an outlet specification of less than 0.1% oxygen by volume.
• What is the specified outlet moisture level? The system is designed for an outlet moisture specification of less than 7 lbs/MMSCF, subject to design feed and operating conditions.
• What heaters are included? The system incorporates a 90 kW electric trim heater and a 35 kW electric regeneration heater and is configured for 3/60/480V electrical service.
• Can Aaron Equipment assist with shipping and logistics? Yes. Aaron Equipment can assist with loading, rigging coordination, domestic and international freight, specialized transportation, and logistics planning for skidded gas-processing and industrial process systems.
