Used- 16,000 Litre Glass Lined Reactor, Model BE16000

Stock# 45392007

Image 1 - Click to Enlarge

DOWNLOAD ALL PHOTOS FOR THIS ITEM

Used- 16,000 Litre Glass Lined Reactor, Model BE16000

Stock # 45392007

ITEM SOLD!

View All 47 available items

or

HAVE A SIMILAR MACHINE FOR SALE?

DESCRIPTION

Used- Tycon Model BE16000 Approximately 16,000 Litre Working Capacity Vertical Glass Lined Reactor. Unit has welded dished top and bottom heads. Internal rated 6 bar/full vacuum design pressure at -45 to 200 deg C. External mild steel jacket rated 6 bar/full vacuum design pressure at -45 to 200 deg C. Includes top entry 2-tier, 4-blade retreat curve cryolok and 4-blade paddle Cryolok agitator with top mounted drive. Unit mounted on lugs.

DESCRIPTION

Used- Tycon Model BE16000 Approximately 16,000 Litre Working Capacity Vertical Glass Lined Reactor. Unit has welded dished top and bottom heads. Internal rated 6 bar/full vacuum design pressure at -45 to 200 deg C. External mild steel jacket rated 6 bar/full vacuum design pressure at -45 to 200 deg C. Includes top entry 2-tier, 4-blade retreat curve cryolok and 4-blade paddle Cryolok agitator with top mounted drive. Unit mounted on lugs.
