Used Hydraulic Presses

Stock# 47463001

Used- Held Technologies Isobaric Double Steel Belted Press. Belt width: 1.04 meters. Inside seal width: 0.91 meters. Gap range: 0.1 mm to 50 mm. Isobaric pressure up to 40 bar (580 psi). 5 temperature zones, 3 include active cooling, temperature range up to 240 degrees C. Speed Range: 0.2 to 6 meters/minute. Also includes Century Design hot melt coating cell with fiber pulls. Resin melt plate with filming rolls. Web tension control system, film/fabric let off edge guides.

Stock# 40657023

Used- Multipress, Model W3T120M, 12 tons. Includes a Model IT06-6 index table with time delay, and stainless steel platens.

Stock# 44838001

Used- PHI Pasadena Hydraulics Inc Multilayer Unitized Frame Compression Press, 30 Tons, Model 30U1212S-3KCS-N-MS7-P. Die space 12" left to right x 12" front to back. 5" Diameter upacting gravity return cylinder, 4" ram stroke, (3) 12" x 12" electrically heated, water cooled platens, temperature 25 to 800 degrees F, (1) 1.5 hp, 3/60/440 volt 1200 rpm motor. Built in controls with temperature controller.

Stock# 40101001

Used- PHI Multi Daylight 50 Ton Upacting Hydraulic Compression Press, Model SB534C-MS-X19-24.(5) cored platens 12 5/8'' left to right x 12 5/8'' front to back. Includes an X19 Automatic Data Logger, 1 1/2 HP, 3/60/480 Volt, 1200 RPM motor. Includes temperature controllers.18265 hours on meter.

Stock# 43256001

Used- Carver Air Powered Up Acting Hydraulic Press, 60 Ton Capacity, Model 2202-AIR. (2) 18" X 18" Electrically heated, water cooled platens. 6" Diameter ram, up strike 8". (4) 2" Diameter tie bars, clearance left to right 18-1/2". 16" Daylight opening. Includes a 4.5 kw platen temperature controller.

Stock# 48017005

Used- 100 Ton Hamilton Gib-Guided Compression Modling Press, Model 100AP082. Max. stroke 30”, max. daylight to bed 48” (18” shut height), bed area 127” right to left x 74” front to back, (30” floor to bed). Ram area 127” right to left x 88” front to back. Window size 76” wide. Hydraulics-crown mounted 60 hp, 230/460 2-speed motor. Vickers pumps number pv040-31h01-u8, piston pump number v45vtbs60s, vane pump. 3-cylinders down acting, Allen Bradley slc 5/04 and slc 500 controllers. Panelview 600. Overall dimensions 15' high, 17' right to left.

Stock# 46887001

Used- Wabash 100 Ton Upstroke Hydraulic Molding & Laminating Press, Model PC-100-2424-4TM. 4 Post upstroke type, floor standing, 2 opening. Distance between 3" diameter posts: 28" left to right x 15" front to back. Platen area (nominal) 26" left to right x 25" front to back. Overall platen dimensions: 37" left to right x 25" front to back. Stroke of fully guided platen: 0-7" maximum. Daylight opening (total) 21" maximum. Daylight opening between hot plates: 3.5" maximum. (4) Hot plates 24" left to right x 24" front to back x 2" thick, electrically heated to 600 degrees F, water cooled. (4) Insulation 24" left to right x 24" front to back x 1" thick. Main ram diameter 7"-3" at 2600 psi - 100 tons. Floor to top of moving platen 36". Power unit base of press (2) hydraulic pumps driven by 3 hp, 3/60/230/460 volt, 1750 rpm. Speeds approximate 40" minute closing, 2" minute pressing to 100 tons, 50" minute return. Controls: push button operation with stroke and pressure control, dual palm buttons, (4) temperature controllers, selector switch for manual or semi-automatic operation. Cycle timers low pressure, high pressure, water, air, air purge. Low and high pressure gauge. Serial# 8171.

Stock# 43158001

Used- 125 TON WABASH MOLDING AND LAMINATING PRESS Hydraulic Model PC125-2424-2TM 4-post upstroke type Floor standing Distance between 3" dia. posts: 28" L-R x 15" F-B Platen area (nominal): 28" L-R x 25" F-B Overall dimension of platen: 37" L-R x 25" F-B Stroke of fully guided platen: 0-7" maximum Daylight opening (total): 13" maximum Daylight opening between hot plates (1): 6" maximum Hot plates (2): 24" L-R x 24" F-B x 2" thick (Electrically heated to 600 F- water cooled) Main ram diameter (2): 8"/3.5" @ 2486 PSI - 125 tons Power unit (base of press): Combination hydraulic pump, driven by 5 HP 1740 RPM 230/460/3/60 motor Speeds approx.: 55"/minute closing 3"/minute pressing to 125 tons 65"/minute return Controls: Pushbutton operation with stroke & pressure control Dual palm buttons Cycle timers - low pressure, high pressure, water, air, air purge (2) digital temperature indicating controllers Low & high pressure gauge Weight approx. 7500# Overall dimensions approx. 60" L-R x 48" F-B x 72" H Serial no. 6828

Stock# 48416001

Used-Beckwood Hydraulic Press, Model 1502862. 4-Post, 150 Ton Down Action Straight Hydraulic Press. Rated for 80 Ton punching capacity) for moderate off center loading with a housing clearance of 62" right to left and 28" front to rear and .3" x 36" x 60". Blanchard Ground Steel Platens welded on the bed and ram. Each platen will have five T-slots to accept 5/8" T-bolts each with one on center front to rear and two spaced on 12" centers from center. Stroke: 12" stroke with full rated tonnage throughout the stroke. Stroke is fully adjustable from 0" to 12" to reduce any point of operation hazards and to reduce the cycle time where fewer strokes are required. Shut Height: 4.5", Daylight" 16.5"

Stock# 48416002

Used-Beckwood Hydraulic Press, Model 1502862. 4-Post, 150 Ton Down Action Straight Hydraulic Press. Rated for 80 Ton punching capacity) for moderate off center loading with a housing clearance of 62" right to left and 28" front to rear and .3" x 36" x 60". Blanchard Ground Steel Platens welded on the bed and ram. Each platen will have five T-slots to accept 5/8" T-bolts each with one on center front to rear and two spaced on 12" centers from center. Stroke: 12" stroke with full rated tonnage throughout the stroke. Stroke is fully adjustable from 0" to 12" to reduce any point of operation hazards and to reduce the cycle time where fewer strokes are required. Shut Height: 4.5", Daylight" 16.5"

Stock# 48017003

Used- 200 Ton Verson Gib Guided Hydraulic Press, Model 200-HDI-84. Max. stroke 40”, max. daylight to bed 60” (55” over 5” bolster), max. shut height to bed 20” (15” over 5” bolster). Bed area 84” right to left x 48” front to back (41” floor to bed). Ram area with 8pt. gibs 84” right to left x 48” front to back – gib guided. Ram speeds 730/93/730 ipm. Hydraulics-crown mounted 50 hp, 220/440, 880 rpm motor with oil gear number d-6025 pump (rebuilt 1996). 30 hp, 220/440 cushion motor/pump. 14-1/4” diameter cylinder – 275 gallon tank. Overall dimensions 19' high, 117” (108”) right to left, 96” (67”) front to back, tank – 81” high, 87” right to left, 65” front to back.

Stock# 48017001

Used- 300 Ton Premier Mold 4-Post Hydraulic Press. Max stroke 61". Max daylight to bed 100". Overall bed and ran area 100". Right to Left x 91" front to back. Distance between the posts is 72". Right to left x 72" front to back. Usable that area 72" right to left x 91" front to back. Distance the floor to bed is 47", 7" diameter posts, (2) 12" diameter bore cylinders, 8" rods, 50 hp and 25 hp motors 3 phase / 60 cycle / 230-460 volt. 1 rexroth piston pump #PV2V4XX150R012,Rexroth vane pumps, relay logic controls, overall dims: 20 height x 96" right to left x 9 front to back.

Stock# 48017002

Used- 300 Ton Verson High Speed Hydraulic Press, Model 300-HD2-120-60T. Max. stroke 28”, max. daylight to bed 82”. Overall bed area 120” right to left x 60” front to back. Ram speeds 1200/600/270/1250 ipm. Ram area 120” right to left x 72” front to back. Window size 52” wide, 300 hp motor, oilgear pump and valves, (new pump in 2000). 750 gallon tank all crown mounted. Controls unico-with Allen Bradley number 5/02 plc. Approximate overall dimensions 24' high, 14' right to left, 12' front to back.

Stock# 42700008

Used- 400 Ton Greenerd H Press, Model IICTG-400. Housing type - 8PT Gibbing - floor standing. Distance between side housings 65.5" L-R. Area of bed (nominal) 60" L-R x 39" F-B. Bed bolster 60" L-R x 39" F-B x 6" thick (T-Slotted). Area of slide (nominal) 58" L-R x 33" F-B. Slide bolster 58" L-R x 33" F-B x 5.5" thick (T-Slotted). Stroke Of gib guided slide 0-10" max. Daylight opening (total) 36" max. Daylight opening between slide and bed bolster 24" max. Main ram diameter 18"/ 17.25" at 3144 PSI - 400 tons. Windows 18" L-R. Floor to Top of bed 41". Power unit (top of press) hydraulic pump driven by 50 hp 1200 rpm 230/460/3/60 motor. Speeds 750"/min. - closing. 27"/min. - pressing to 400 tons. 666"/min. - return. Controls pushbutton operation with stroke and pressure control. Greenerd operator programmer. Selector switch for manual or semi-automatic operation. Dwell timer, isolator press pads, pressure gauge. Mfg. 1987.

Stock# 48017006

Used- 500 Ton Sutherland Gib-Guided Hydraulic Press, Model ID-500. 39.3" Max. Stroke, 51" Max. Daylight to Bed; 98.4" RL x 65" FB Bed Area, 60" Floor to Bed. 825/52/708 IPM. 98.4" RL x 65" FB Ram Area. Bolster Size 12" x 98.4" RL x 65" FB, 33" x77". 100 HP motor, pump and tank crown mount with controls. Overall dimensions 23' overall height, 12'11" RL, 8 FB with hydraulics. Approximately 100,000 lbs. Mfg. 1984

Stock# 42700009

Used- 600 Ton KR Wilson Hydraulic Press. 4 post downstroke type. Floor standing. Distance between 7" diameter posts 120" L-R x 47.5" F-B. Area of bed (nominal) 120" L-R x 66" F-B. Overall dimension of bed 138" L-R x 66" F-B. Bed bolster 119" L-R x 60" F-B x 6" T (T-slotted). Area of slide (nominal) 120" L-R x 66" F-B (T-slotted). Overall dimension of slide 138" L-R x 66" F-B. Stroke of fully guided slide 0 - 36" maximum. Daylight opening (total) 42" maximum. Daylight opening (over bolster) 36" maximum. Main ram diameter 20" at 3070 PSI - 482 tons. Side ram diameter (2) 7"/5" at 3070 PSI - 118 tons. Floor to top of bed 42". Power unit (top of press) Oilgear model PVQ32LSAYCNSN hydraulic pump, driven by 60 hp 1775 rpm 230/460/3/60 motor. Controls Pushbutton operation with stroke and pressure control. Dual palm buttons. Selector switch for manual or semi-automatic operation. Safety slide lock. Pressure gauge. Overall dimensions approximately 155" L-R x 90" F-B x 232" high.
