BUY USED BELT DRYERS FROM AARON EQUIPMENT

8 Items

Below is Aaron's inventory of unused and used belt dryers. If you are looking to sell your used belt dryer submit a request online or contact Erik Eichert at 630-238-7480.

8 Items
Page View: Sort By:

46321001

Used Belt-O-Matic Belt Dryer. Model 125B2X. Design: Convection, hot air; 22 long two pass air up drying, 10 long single-pass air down cooling. Size: 2 wide x 24 long top pass, 2 wide x 36 long bottom pass. Shipping dimensions (before crate and with spreader off): L 37 H 8 2" W 3 10". Operation: Min/Max air temp for drying: Normally 240F, can be as high as 300F. Cooling air temp: Ambient. Min/Max Btuh: 0.25 to 1.5 mmbtuh. Min/Max airflow: 3,000 to 10,000 ACFM. Product depth range: 2" to 6". Min/max belt speed: 0.27 to 1.37 FPM. Motors, gear reducers, and bearings: Leeson brand TEFC motors (wash guard, epoxy coated), 1750 RPM. Leeson brand Ironman gear reducers (epoxy coated). Nickle-plated bearings. 5-Hp Fan 2X -Hp conveyor with 3750:1 ratio gear reducer. 1-Hp oscillating tube spreader. Electrical and controls: Pre-wired electric control panel (can be made UL for $2800) mounted on side of the dryer. 480 volts, 3 phase, 60 cycles, 30 amps (main disconnect included) Water tight plastic conduit Leeson brand sub-micro series variable drives on fan and conveyor motors. 2X High temperature limit safety switches, N/C snap disk (bottom air plenum and exhaust air plenum) 4X dial temperature thermometers, one in each air plenum. Partlow 70 series gas modulating valve (set bottom air plenum temp), 1 " 2X Asco gas safety solenoid valves, 1 . Fireye M series flame monitor. Dwyer vacuum airflow switch. Construction: 304SS inside, outside and structure (16 ga inner and outer sheet metal, 2"x 2" square tube frame) 2" thick insulation in walls and ceiling, rated for 300F.Oscillating tube product spreader (vertical swing spout). Right handed drive side (facing product discharge). 28" dia vane axial fan, alum fan blades and hub, 8 blades, adjustable pitch. Large side wall doors for inspection and cleaning (bolt handle shut for safety). Bottom flat floor (manual clean out). B-60-48-16 304SS woven wire conveyor belt. Traction conveyor drive; ru more info...

  • Compare
  • |
  • Width (in):
  • |
  • Len (in):
  • |
  • Material:
  • |
  • Mfr: Belt-O-Matic
  • |

46514001

Used- Wolverine Corporation Jetzone, Dryer (Fluid Bed), Model DH-103, Est. mfd. 1995. Includes: 10' 6" wide x 34' long x 7' high dryer body, 2 zone, natural gas fired. All 304 stainless steel construction. 7' wide x 42' long food grade slat type pass through conveyor, self-supporting, with stainless steel head and tail sections, 10 hp motor and drive, rated at 107 FPM. (2) Coil boxes, Wolverine Jetzone, Model DH-103, 3 bank, 125 psi boiler capacity, 8' wide x 9' long x 8' high, with stainless steel ductwork (in/out), 2" fiberglass insulation, each with New York blower Model PLR-36 Fan, 35,000 CFM, 100 hp motor and drive, ect. Condensate receiver / pumping return system, Bell and Gossett. (2) 7.5 hp motors, starters, level controls, traps, isolation valves, ect. (2) Micro rotary screeners, product engineered systems, 6' deep x 2' wide x 5 pockets, stainless steel with controls, ect. 10 hp motor and drive, rated at 107 FPM. more info...

  • Compare
  • |
  • Width (in):
  • |
  • Len (in):
  • |
  • Material:
  • |
  • Mfr: Wolverine
  • |

85142

Used- Berndorf Belt Systems (BBS) Inclined Belt Flaker. All sanitary stainless steel construction including drums, belts, frame and enclosure, continuously cooled belt surfaces, cooling medium in drums. Drums are 12" wide x 24" diameter. more info...

  • Compare
  • |
  • Width (in): 12
  • |
  • Len (in): 72
  • |
  • Material: Stainless Steel
  • |
  • Mfr: Berndorf
  • |

43792002

Used- JWI “J” Mate Continuous Dryer, Model J120-GAS, Carbon Steel. Gas heated, working capacity water removal rate 47 pounds an hour (21.3 liters). Includes a top end feed hopper with lump breaker, driven by a 3/4 hp DC gear motor, (1) 14” wide x approximately 144” long stainless steel mesh inclined belt conveyor, driven by a 1/2 hp gear motor, approximately 120” drying section, (1) 1 hp blower, end discharge with chute, approximately 46” discharge height. Base mounted. more info...

  • Compare
  • |
  • Width (in): 14
  • |
  • Len (in): 144
  • |
  • Material: CS
  • |
  • Mfr: JWI
  • |

82714

Used- Berndorf Inclined Cooling Belt. 33" wide x approximately 192’’ long stainless steel belt. Includes a control panel, pump for spray water system, air cylinder for belt tensioning, and a hammermill style chipper at belt discharge end. Requires motor for belt. Mounted on a carbon steel frame. more info...

  • Compare
  • |
  • Width (in): 33
  • |
  • Len (in): 192
  • |
  • Material: Stainless Steel
  • |
  • Mfr: Berndorf
  • |

82713

Used- Berndorf Inclined Cooling Belt. 39" wide x approximately 192'' long stainless steel belt. Includes a control panel and a Hammer Mill style chipper at belt discharge end. Requires motor and sprockets for belt. Mounted on a carbon steel frame more info...

  • Compare
  • |
  • Width (in): 39
  • |
  • Len (in): 192
  • |
  • Material: Stainless Steel
  • |
  • Mfr: Berndorf
  • |

42263001

Unused- Berndorf Belt Systems Belt Cooler. The unit is inclined with Endless 'Double' Belt Cooling Conveyor, 40" wide, Model BBS, NC31 stainless steel. Designed capacity for 1/8" thickness of toner, 725 pounds an hour at a feed temperature of 356 degree F, removal temperature 102 degree F. Upper belt 72" long x 0.040 thick, upper belt height feed end 76-7/8", discharge height 96-5/8"; lower belt 108" long x 0.040 thick, lower belt height feed end 34-1/4", discharge end 73-1/4". Belts driven by a 2 hp, 3/60/230 volt gear motor, belt speed approximately 10-50 feet per minute. Includes a squeeze roll assembly with a 2 hp motor, water tank assembly, and a lower end discharge product breaker assembly with a 2 hp motor. Mounted on a carbon steel frame with casters. Berndorf is similar to Sandvik. Built 2006. more info...

  • Compare
  • |
  • Width (in): 40
  • |
  • Len (in): 108
  • |
  • Material: 431 Stainless Steel
  • |
  • Mfr: Berndorf
  • |

77404

Unused- Proctor & Schwartz Cotton Liner Dryer System, Carbon Steel. Capacity: 3000 lbs/hour. Moisture content entering dryer max 10%, average 7% SDB. Moisture content leaving dryer 0.4%-1.0% SDB. Calculated temperature in dryer 230 degrees F. Steam required at 90-100 psig approximately 1100 lbs/hour. Total connected system HP=60. Dryer consists of linter bale feeding table, approximately 4' wide x 8' long. Type 570 picker with magnet trunk, with 30 hp motor. Type 683 single drum condenser with 1 hp motor and type 660 bag collector. Type 75BA-00 linter feeder, type SCF cotton linter dryer with cross delivery conveyor, 24 foot belt, 1 hp motor, exhaust fan and condenser fan - 15 hp. Built in 1974. more info...

  • Compare
  • |
  • Width (in): 48
  • |
  • Len (in): 96
  • |
  • Material:
  • |
  • Mfr: Proctor & Schwartz
  • |
