Clinton Biofuels Biodiesel Refinery. Typical batch size 10,000,000 gallons per year from soybean oi...
Used- Clinton Biofuels Biodiesel Refinery. Typical batch size 10,000,000 gallons per year from soybean oil. Plant also ran corn oil tests at 4,000,000 gallons per year. Partial equipment list includes (6) Mueller Distillation Columns, (1) Methanol Stainless Steel Column with a SRS methanol feed system, (1) SRS Resin Based Pre Treatment Systems, Designed to lower FFA (Free Fatty Acids). Consists of (4) resin tanks, (2) flash tanks, (1) Methanol recovery tank. Frame mounted. (1) CEI Enterprises Hot Oil Heater, Model CEI-80, (1) Thermal Fluid Systems Hot Oil Heater, (1) Harvest Energy Acid Degumming System Consisting Of: Alfa Laval WHPX510TGD24-60HZ Disc Centrifuge. Driven by a 15kw motor. Serial# 2965556. Includes a Harvest Energy rectangular 316L stainless steel oil/water sump tank, approximate 300 total gallons, serial# 0901141. Silverson High Shear In-Line Mixer, Model 450LSB1468, Stainless Steel. Driven by a 15hp motor. Serial# 31-450LS. Goulds 3196 Centrifugal Pump, Size 1.50X3, Carbon Steel. Driven by a 3hp motor. Serial# 743C880. Goulds 3196 Centrifugal Pump, Size 1.50X3-8, Carbon Steel. Driven by a 3hp motor. Serial# 788E639. Goulds 3196 Centrifugal Pump, Size 1.50X3-8, Carbon Steel. Driven by a 3hp motor. Serial# A748F338. Maag Gear Pump, Model G1-24-01008, Carbon Steel. Driven by a 3hp motor. Serial# 0021450772, built 2013. Constructora Quimica Glycerin Neutralizer Pressure Tank, Approximate 65 Gallon, Duplex Stainless Steel, Vertical. Approximate 20" diameter x 48" straight side, dished top and bottom. Internal rated 50 psi at 300 degrees F. Includes a top mounted Lightnin agitator model X5S25 with a motor. Mounted on 4 carbon steel legs. Serial# 30317B, built 2007. Constructora Quimica Reactor, Approximate 825 Gallon, Stainless Steel, Vertical. Approximate 52" diameter x 86" straight side, dished top and bottom. Internal rated 50 psi at 300 degrees F., 43" section of dimple jacket on sidewall and bottom head, not rated. Includes a top mounted Lightnin agitator model 15S2 with a motor. Mounted on 4 carbon steel legs. Serial# 30326B, built 2007. Harvest Energy Shell & Tube Heat Exchanger, 99.5 Square Feet, Carbon Steel, Horizontal. Shell rated 150 psi at 400 degrees F., tubes rated 150 psi at 375 degrees F. Serial# 091141, built 2014, (14) Mueller shell & tube heat exchangers, (2) Pfaudler Wiped Film Evaporators, (20) Mueller Pressure Tanks, (1) Marley 220 Series Single Cell Cooling Tower, (1) Evapco Induced Draft Counterflow Cooling Tower, Model AT 19-56, (1) Advantage Engineering 3 Cell Fiberglass Cooling Tower System, (6) 30,000 gallon carbon steel aboveground flammable storage tanks, (2) 20,000 gallon carbon steel aboveground flammable storage tanks, (3) 15,000 gallon carbon steel aboveground flammable storage tanks, (1) Olympian 125KW Back Up Diesel Generator, Model D125P1, (3) poly storage tanks, (1) Praxair Laserstar 1530 Laser Assist Gas Generator, (2) Ingersoll-Rand Compressors, Model SSR UP6-25-125. Serial# PX6732U06093, PX6731U06093, (1) Kaeser Compressor, Model ASD25T, (1) Kaeser Air Dryer, Model KAD-165, Serial# 10000002875294, (2) Krystil Klear Filtration Multi-Round Liquid Bag Housings, (2) Budzar Chillers, (1) GE Osmonics Reverse Osmosis System, Model RO-E4H-27K-DLX. Rated 18.8 gallons per minute. Serial# 06-1200066-02. Includes (5) cartridges, 10hp pump, 2hp pump, poly tank and a water softener, (1) Flexicon Supersack Unloader. Consists of a Yale 2 ton hoist, stainless steel hopper, manual butterfly valve, manual dust sleeve, Flexicon flexible screw conveyor with hopper and dust collector, control panel, and a stainless steel frame approximate 60" wide x 60" long x 16 tall, miscellaneous pumps, valves and controls.
