Below is Aaron's inventory of unused and used glass lined tanks. If you are looking to sell your used glass lined tank submit a request online or contact Michael Cohen at 630-238-7480.
Used- Ace Glass vessel more info...
Used- ACE glass vessel more info...
Used- De Dietrich Glass Lined Pressure Tank, 182 Liter (48.09 Gallon), 3008 Glass, Horizontal. Approximate 18’’ diameter x 30’’ straight side. Dished ends, (1) removable. Internal rated -1 to 4 bar (-14.5 to 58 psi) at -10 to 200 degrees C. (14 to 392 F.) Openings top (2) 2’’, 4’’, ends 2’’, 2’’ end bottom outlet. Mounted on removable wood saddles with a carbon steel cart with casters. more info...
USED- Pfaudler Glass Lined Receiver Tank, 50 Gallon, 9115 Glass, Vertical. Approximately 24" diameter x 23" straight side. Dish bolt-on top, dish bottom. Internal rated 150 PSI/FV at 450 Degrees F. Openings: top (2) 2", 3", 4", 4" hand hole with sight glass cover; 2" center bottom outlet. Mounted on 3 carbon steel legs. more info...
Used-Pfaudler Glass Lined Pressure Tank, 50 gallons, vertical. 24" Diameter x 24" straight side. Dish bolt on top, dish bottom. Internal rated 150 psi/fv at -20 to 450 deg F. Openings: top (3) 2", 3", 4" sight glass; 2" center bottom outlet. Mounted on 3 carbon steel legs with a cart with casters. Built 2001. more info...
Used- De Dietrich Glass Lined Receiver, 2105 Liter (55.4 Gallon), 3008 Blue Glass, Vertical. 23" Diameter x 28" straight side, dished clamp on top, dished bottom. Internal rated 6/-1 bar (87/-14 psi) at -10 to 200 degrees C. (14 to 392 F.). Openings top (2) 2", 3", 4". 2" Center bottom outlet. Mounted on 3 carbon steel legs, approximate 15" discarge height. more info...
Used- Tycon Glass Lined Receiver, 105 gallon (400 Liter) Horizontal . Internal rated 100 psi/FV @ 450 F. Jacket Rated 100 psi/FV @ 450 F. Glass type 808 Blue. S# 9056, NB# 18, Built in 2001, Weight 2022 lbs. more info...
USED: Dedietrich Glass Lined Pressure Tank, 125 gallon, 3008 glass, vertical. 31" diameter x 37" straight side. Dish bolt-on top, dish bottom. Internal rated 100/FV psi at 400 deg F. Openings: top (3) 3", 4"; 2" center bottom outlet. Mounted on 3 stainless steel legs. Approximate 3" discharge height. Built 1982. more info...
Used-Glass Lined Tank, 500 liter capacity, 900 mm diameter x 900 mm high, jacketed, dish top and bottom with 1-1/2' center discharge. Tank Specifications: Class 2A, max work pressure 276 Kpa or full vacuum, design temp 200 degrees C. Jacket Specifications: Class 2B, max work pressure 517 Kpa or 417 Kpa full vacuum. Design temp 200 degrees C. Lining 3115 glass. more info...
Used- Von Roll Glass Lined Pressure Tank, 630 Liter (166.48 Gallon), Horizontal. Approximate 27’’ diameter x 62’’ straight side. Dished ends, (1) removable. Internal rated 2 bar ( psi) at 200 degrees C. (392 F.) Openings top (2) 4’’, ends 3’’, 3’’ end bottom outlet. Mounted on removable saddles with a carbon steel cart with casters. more info...
Used- Pfaudler Glass Lined Receiver, 1000 Gallon, Vertical. 60" Diameter x 72" straight side, dish top and bottom. Internal rated 50 psi/fv at 450 deg F, type 5014 glass. Leg supports. Openings: top 18", (3) 3"; 3" center bottom outlet.. more info...
Used- Pfaudler Glass Lined Reciever, 1000 gallon, 9129 white glass, model VC60-1000. 60'' diameter x 78'' straight side. Dished top and bottom. Internal rated 100 psi/FV at 450 deg F. Serial #R292-0271, National Board #2658, built 1993. more info...
Used- Pfaudler Chemstore Closed Glass Lined Tank, 2000 Gallon, Model CH-84-2000, Horizontal. 4024 Glass. 84" Diameter x 72" straight side. Dished ends. Internal rated 35psi/Full Vacuum at 450 degrees F. Openings top (3) 3", 18" man way with cover, 3" end bottom outlet. Mounted on 4 legs. more info...
Used- DeDietrich Glass Lined Tank, 2500 gallon, 3009 blue glass, horizontal. Approximately 78'' diameter x 90'' straight side, dished heads. Internal rated 30/fv at 400 deg F. Top nozzles. Head 18'' manway with cover, bottom approximately 3''. Built 1993. more info...
